Operational Amplifier IC

Filter
View
Showing all 6 Items
  • DC voltage gain: 100 dB
  • Bandwidth (unity gain):  1 MHz
  • Input bias current: 20 nA
  • Input Offset Voltage: 2 mV
  • Input Supply Voltage: Single: 3 -32 volts, Dual: 1.5-16 volts
  • DC voltage gain: 100 dB
  • Bandwidth (unity gain):  1 MHz
  • Input bias current: 20 nA
  • Input Offset Voltage: 2 mV
  • Pins: 14
  • Product type: audio amplifier IC
  • IC number: LM386
  • Number of pins: 8
  • Pin type: Through holes
  • Package: DIP-8
  • Low VOS: 75 µV Max
  • Low VOS Drift: 1.3 µV/°C Max
  • Low Noise: 0.6 µV p-p Max
  • Wide Input Voltage Range: ±14 V
  • Wide Supply Voltage Range: ±3 V to ±18 V
  • Supply Voltage Range: 1.8V to 5V DC
  • Bandwidth: 400kHz
  • Operating Temperature: -40°C to 125°C
  • No. of Amplifiers: 2
  • Slew Rate: 0.1V/µs
