Buck Boost Converter

Filter
View
Showing all 11 Items
  • Input Voltage: 3.2V ~ 35V
  • Output Voltage: 1.23V ~ 30V
  • Maximum Conversion Efficiency: 92%
  • Output Ripple: <30 mV
  • Switching Frequency: 150KHz
  • Maximum Input Voltage (V):   2 to 24
  • Maximum Output Current(A):  2
  • Output Voltage(V):   5 to 28
  • Maximum Efficiency:   93%
  • Dimension: 36 mm * 17 mm

  • Input Voltage Range: 7~40V
  • Output Voltage Range: 1.25~35V
  • Max. Output Current: 10A
  • 95% Conversion Efficiency
  • Operating Frequency: 300KHz
  • Input Voltage: 4.5V – 28V
  • Output Voltage: 0.8V – 20V
  • Output Current: 1.8A (typical), 3.0A (max)
  • Output Voltage Adjustment: Onboard potentiometer
  • Thermal shutdown
  • IC number: TS2596
  • Package:TO-220 (5)
  • Maximum Input Voltage: 40V
  • Output Voltage Range: 1.23V-38.5V
  • Switching Frequency: 150 KHz


  • Input Voltage: 10V-32V DC
  • Max. Input Current: 10A
  • Output Voltage: 12V-35V DC
  • Max. Output Current: 6A
  • Output Power: 150W

  • Input voltage: 5-15V DC power supply
  • Charge status: full and unloaded blue lights, charging red
  • Double 8.4v / 4.2v lithium rechargeable single
  • Programmable charge current. 0. 1A-2A
  • Dimension: 25x18x5mm
  • Input voltage: DC 4V - 38V
  • Output voltage: DC 1.25V - 36V (adjustable)
  • Output current: Maximum output current 5A
  • Output power: It is recommended to use within 75W
  • The efficiency of this regulator is up to 96%
  • Input Voltage: 4V ~ 40V DC
  • Output Voltage: 1.3V ~ 37V DC
  • Output Current: 2A
  • Switching Frequency: 150kHz
  • Operating Temperature: -40°C to +90°C
