Description
Harmony XB5 modular green push-button operates with a spring return/impulse mechanism and uses screw clamp terminals. This push-button provides simple and robust control to machines and processes. It is easily installed into standard 22mm diameter cut-outs and connected with simple screw-clamp connections. Its schematic is clearly distinguishable visually at a distance with clear colours and markings, minimizing errors during initial wiring and later maintenance operations. It is IP66 impact resistant, dust resistant, water-resistant and vibration resistant making it ideal for operation in harsh environments.
Specifications
| Model | XB5AA31N |
| Brand | Schneider |
| Product Type | Push Button |
| Short Name | XB5 |
| Contact Block Rating | 240V 3A |
| Bezel Material | Plastic (Dark Grey) |
| Head Type | Standard |
| Fixing Collar Material | Plastic |
| Mounting Diameter | 22mm |
| Shape of Signaling Unit Head | Round |
| Operator Type | Spring Return |
| Operator Profile | Green Flush |
| Contact Type | 1 NO |
| Contact Operation | Slow Break |
| Size | 52x30x42mm |
| Country of Origin | China |
