Description
It is a hand-held 31/2 digital multimeter for measuring DC and AC voltage, DC and AC current, resistance, diode, transistor, frequency, temperature, capacitance and continuity test and battery operated. The back light of display is optional. It is used for Voltage measurement: High and low value DC measurement and peak to peak and DC average measurement. It is useful for temperature and environmental applications: Low-cost weather station, DMM internal temperature, Resistance measurement: Micro ohm meter, measuring with constant voltage and measuring resistance with constant current.
Features:
- It provides accurate AC /DC voltage , current resistance, etc.
- It has a black light Led screen which makes it easy to read the readings.
- It has high resolution.
- Large Backlight LCD Screen Improves Visibility.
Specifications:
| Model | VC830L |
| Type | Digital multimeter |
| Size | 31.5 x 91 x 189mm |
| Weight | 280g |
| Max. voltage between terminal and ground | 1000V DC or 700V AC |
| Fuse protection | 500mA/250V |
| Power | 9V battery |
| Display | LCD, 1999 Counts |
| Measuring method | Dual- slope integration A/D converter |
| Storage temperature | -10 to 50 Celsius |
| Operating environment | 0 to 40 Celsius |
| Country of Origin | China |
