Description
- Driver Chip: CH340G
- Supports all basic windows versions.
- The adapter plate integrated 1000μF solid capacitors to ensure the current supply
- The power supply will not be a problem to make WIFI module crashes unresponsive.
- Using 3225 SMD crystal oscillator, improve the stability of serial work, on a beautiful and tall.
- Working voltage: 4.5V – 5.5V (Onboard 3.3v LDO Regulator)
- Working current: 300mA (LDO regulator can supply)
| Operating Voltage (VDC) |
4.5 ~ 5.5 |
|---|---|
| Operating Current (A) |
0.3 |
| Driver IC |
CH340G |
| Logic Input (V) |
3.3 |
| Length (mm): |
50 |
| Width (mm): |
18 |
| Height (mm): |
14 |
| Weight (g): |
6 |
| Shipping Weight | 0.01 kg |
| Shipping Dimensions | 6 × 3 × 1 cm |
