Description
- Input voltage: 7 – 26V
- Output voltage: 5V
- Output current: 3A (Max), the current should be controlled within 1.6A for working long hours
- Conversion efficiency: 96% (Max)
- Output ripple: < 30mV
| Input Voltage Range |
7 – 26V |
|---|---|
| DC Output Voltage (V) |
5 |
| Max. Output Current (A) |
3 |
| Conversion Efficiency |
96% (Max) |
| Output Ripple |
< 30mV |
| Operating Temperature (°C): |
-40 to 85 |
| Length (mm): |
17.5 |
| Width (mm): |
12 |
| Height (mm): |
4.3 |
| Weight (g): |
3 |
| Shipping Weight | 0.006 kg |
| Shipping Dimensions | 2 × 2 × 1 cm |
