Description
- Operating Voltage: 12VDC
- Power Consumption: 1.44W
- Body and Blade Constructed from Thermoplastic PBT of UL 94V-0
- Single Phase 4 Pole Brushless DC Motor
- Lubricated Sleeve Bearing System.
- Counterclockwise Rotation Direction if Viewed from front of Fan Blade
| Item Type |
Regular Cooling Fan |
|---|---|
| Dimension (LxH) mm |
80×25 |
| Rated Voltage (V): |
12 |
| RPM |
3200 |
| Color: |
Black |
| Material: |
Metal, Plastic |
| Rated Current (A) |
0.138 |
| Noise Level (dB) |
33 |
| Power Consumption (Watt) |
1.66 |
| Insulation Class |
UL Class A |
| Length (mm): |
80 |
| Width (mm): |
25 |
| Height (mm): |
80 |
| Weight (g): |
75 |
| Cable length (mm) |
300 |
| Shipping Weight | 0.078 kg |
| Shipping Dimensions | 9 × 9 × 1 cm |
