Description
- Operating voltage range from 2V to 3.6V
- 64Kbytes of flash memory
- 20Kbytes of SRAM
- CRC calculation unit, 96bit unique ID
- Two 12bit, 1µs A/D converter (up to 10 channels)
- 7 channel DMA controller, 3 general purpose timer and 1 advanced control timer
- 37 fast I/O ports
- Serial wire debug (SWD) and JTAG interfaces
| Mounting Type |
SMD/SMT |
|---|---|
| Package/Case |
LQFP-48 |
| Minimum Supply Voltage (V) |
2 |
| Maximum Supply Voltage (V) |
3.6 |
| Product Type |
ARM Microcontrollers – MCU |
| Number of ADC Channels |
10 |
| Product Series |
STM32F103C8 |
| Maximum Clock Frequency (MHz) |
72 |
| No. of Timers/Counters |
3 Timer |
| No. of I/Os |
37 |
| Data Bus Width |
32 bit |
| ADC Resolution |
12 bit |
| Interface Type |
CAN, I2C, SPI, USART, USB |
| Program Memory Size (kB) |
64 |
| Data RAM size and Type |
20 kB SRAM |
| Operating Temperature (°C): |
-40 to 85 |
| Dimensions (mm) LxWxH |
7 x 7 x 1.4 |
