Description
- Input Voltage: 100-240VAC, 50/60Hz
- Output: 12V 5A
- Plug Type: Indian three Pin
- Adapter Output Plug size: 5.5mm
- Overall Lenght with Cable: 2.3 Meter
| Model |
Orange 12V 5A |
|---|---|
| Output Plug Size (mm) |
5.5mm (Outer Dia) x 2.5mm(Inner Dia.) |
| Input Voltage (V AC) |
100 ~ 240 |
| Output Voltage(V) |
12 |
| Max. Output Current (A) |
5 |
| Output Power(Watt) |
60 |
| Ripple wave (mVp-p) |
<1% |
| Linear Modulate |
0.5%max |
| Temperature Coefficient |
0.02% |
| Start Time(s) |
1 |
| Guard Time(ms) |
20 |
| Override Protection |
115%-150%kvA |
| Overvoltage Protection |
30%-150% VAC |
| Short-Circuit Protection |
1 Channel Automatic Recovery |
| Operating Temperature (°C): |
0 to 40 |
| Store Temperature (°C) |
-20 – +85 |
| Output Adapter Type (mm) |
5.5 x 2.5 |
| Power Cord Length (Meter) |
1.2 |
| Dimensions in mm (LxWxH) |
110x50x30 |
| Weight (g): |
190 |
| Overall length with Cable |
2.3 Meter |
| Shipping Weight | 0.295 kg |
| Shipping Dimensions | 12 × 6 × 4 cm |
