Description
It's an SN7494N 4-Bit Shift Register Parallel IN Serial OUT. This is a 14-pin IC whose operating voltage is 7V DC and Its operating temperature is maximum of 70 degree Celsius. Parallel IN Serial OUT" register‚ the data is entered in a parallel way‚ and the outcome comes serially. The input of the flip flop is the output of the previous Flip Flop. The input and outputs are connected through the combinational circuit. Through this combinational circuit‚ the binary input B0‚ B1‚ B2‚ and B3 are passed. The shift mode and the load mode are the two modes in which the "PISO" circuit works.
Features
- It's a 4 Bit Shift register
- It's a 14 pin IC
- It's operating Voltage is 7V DC
| Specifications | |
|---|---|
| Supply Voltage | 7V Dc |
| No. of Bit | 4 |
| Part Number | SN7494N |
| Temperature | 70 degree C |
| Logic Family | TTL Logic Family |
| Mounting Type | Through hole |
| Package | DIP-14 |
| No. of Pins | 14 |
| Type | Shift Register |
