Description
- 2GB/4GB/8GB Variants
- Quad-Core 64-bit Broadcom 2711, Cortex A72 Processor
- WLAN 802.11 b/g/n/ac (2,4 + 5,0 GHz)
- LAN RJ45 10/100/1000 Mbit (Gigabit LAN over USB 3.0)
- Operating Power 5V@3A via USB Type-C Port
| Operating Power |
5V 3A DC via GPIO Header, 5V 3A DC via USB Type-C Connector, Power Over Ethernet (PoE)–Enabled (requires separate PoE HAT) |
|---|---|
| GPIO |
(Fully backwar ds-compatible with previous boards), Standard 40-pin GPIO Header |
| Multimedia |
H.264 (1080p60 decode, 1080p30 encode);, H.265 (4Kp60 decode);, OpenGL ES, 3.0 Graphics |
| Video and Sound |
2 × micro HDMI ports (up to 4Kp60 supported), 2-Lane MIPI CSI Camer a Port, 2-Lane MIPI DSI Display Port, 4-Pole Stereo Audio and Composite Video Port |
| Clock Speed |
1.5 GHz |
| Micro-SD Card Slot |
Yes (FAT32 format), support maximum 32G Micro SD Card Memory Features |
| Operating Temperature (°C): |
0 to 50 |
| Dimensions (mm) LxWxH |
85 x 56 x 19 |
| Weight (g): |
52 |
| UPC |
696583082139 |
| Shipping Weight | 0.057 kg |
| Shipping Dimensions | 10 × 6 × 2 cm |
