Description
- RAM: 1GB
- Processor: Broadcom BCM2837 chipset 1.2GHz Quad-Core ARM Cortex-A53 (64Bit)
- 802.11 b/g/n Wireless LAN and Bluetooth 4.1 (Bluetooth Classic and LE)
- Storage : SD/MMC/SDIO
- Power: 5V / 700mA~3A via micro USB
| Model |
Pi 3 – Model B (Original) |
|---|---|
| Clock Speed |
1.2 GHz |
| Dimensions (mm) LxWxH |
85 x 56 x 17 |
| On Board Ports |
10/100 BaseT Ethernet socket, 15-pin MIPI Camera Serial Interface (CSI-2), 4 x USB 2.0 Connector, 40-pin 2.54 mm (2×20 strip) GPIO, Combined 3.5 mm audio jack and composite video, Composite RCA (PAL and NTSC), HDMI (rev 1.3 & 1.4), Push/pull Micro SD I/O |
| Operating Power |
5V, 2.5~3A |
| Processor |
Broadcom BCM2837 chipset, 1.2GHz Quad-Core ARM Cortex-A53 (64Bit) |
| RAM |
1GB LPDDR2 |
| Micro-SD Card Slot |
Yes |
| Weight (g): |
44 |
| Shipping Weight | 0.047 kg |
| Shipping Dimensions | 8 × 6 × 4 cm |
