Owon SDS 1102 100 MHz Digital Storage Oscilloscope
The Owon SDS1102 Digital Storage Oscilloscope 100 MHz offers a 7-inch color LCD screen with 800x600 resolution. The SDS1052 has a ultra-thin body at only 70mm deep for portability, and it offers a 10K record length per channel of memory.
Also, order the SPE3102 Owon DC Power Supply – Perfect for testing!
- AUTOSET function for setting display parameters (time base, gain)
- compact design
- FFT analysis
- mathematical functions: addition, subtraction, multiplification, division and signal phase reversing
- X-Y operation mode
Applications:
- Electronic circuit debugging
- Circuit testing
- Design and manufacture
- Education and training
- Automobile maintenance and testing
Specifications:
| Feature | Details |
|---|---|
| Manufacturer | OWON |
| Type of oscilloscope | Digital |
| Number of channels | 2 |
| Bandwidth | 100MHz |
| Sampling rate | 1Gsps |
| Memory record length | 10kpts |
| Display type | LCD 7" (800x480) |
| Trigger modes | Automatic, Normal, Single |
| Trigger types | Falling-edge, Rising-edge, Video signal |
| Time base | 2ns/div to 1ks/div |
| Max. input voltage | 400V |
| Vertical resolution | 8-bit |
| Input coupling | AC, DC, GND |
| Interface | USB |
| Manufacturer series | SDS |
| Rise time | ≤3.5ns |
| Input impedance | 1MΩ/20pF |
| Input sensitivity | 5mV/div to 5V/div |
| Plug variant | EU |
| Power consumption | 15W |
| Weight | 1.1kg |
| Dimensions | 301 x 152 x 70mm |
| Measurement memory | 16" |
