Description
SMD LEDs are substantially smaller than lead frame type components, they can be used on smaller boards, with higher packing density, less storage area, and smaller equipment. Mono Colour and Lead-free.
Applications:
- Backlighting in dashboard and switch.
- Telecommunication: indicator and backlighting in telephone and fax.
- Flat backlight for LCD, switch and symbol.
Specification
| Package | 1206 |
| Mounting | SMD |
| Colour | Orange |
| Wavelength | 600.5-605nm |
| Operating Voltage | 1.75V-2.35V DC |
| Operating Current | 20mA |
| Operating Temperature | -40°C to 85°C |
| Viewing Angle | 130° |
| Country of Origin | China |
