Description
The MY1016ZL is a 24V 250W PMDC (Permanent Magnet DC) motor designed specifically for electric wheelchairs. It features an electromagnetic brake system that provides reliable stopping power and safety. This motor is ideal for mobility applications where precise control and smooth operation are essential. With its compact size and efficient performance, the MY1016ZL ensures a comfortable and reliable driving experience for wheelchair users. The electromagnetic brake enhances safety by quickly stopping the wheelchair when needed, making it suitable for both indoor and outdoor use. Overall, this motor combines power, reliability, and safety features, making it a popular choice for electric wheelchair applications.
Specifications:
- Model: MY1016ZL.
- Working voltage: 24V.
- Starting Current: 3A.
- Rated Torque: 36Nm.
- Noise: <60DB.
- Wheelchair motor output power: below 1100W.
- Operating speed: un-load 75 rpm or 120rpm;
- Reduction Ratio: 40:1.
- Installation structure: end face.
- Function type: wheelchair.
- Protection form: IP44.
- Insulation class: E.
- Power supply type: DC
