Description
The MY1016Z2 is a reliable 24V 250W PMDC motor designed for electric wheelchairs, offering a speed of 120 RPM. Its integrated brake system ensures safe and smooth stops, making it suitable for e-bikes as well. This motor combines power and efficiency, providing ample torque for uphill climbs and steady performance on flat terrain. Its compact size and durable construction make it ideal for retrofitting or upgrading existing e-bike systems. With its low maintenance requirements and consistent performance, the MY1016Z2 motor is a practical choice for enhancing the ride experience of electric wheelchairs and e-bikes alike.
Specifications:
- Working Voltage: 24V
- Rated Power: 250W
- Shaft Type: Key shaft
- Rated Speed: 120RPM
- Rated Torque: 15 N.m
- Based motor RPM: 3700RPM
- No load current: 4.0A
- Rated Current: 14.8A
- Motor efficiency: 76%
- Insulation class: E
- Shaft Diameter: 17mm
- Shaft Length: 46mm
- Protect Grade: IP33
- Weight: 3.12 kg
Package Includes:
1x MY1016Z2 24V 250W DC Motor
