Description
- Overload protection on the input and output
- No latch-up when the common mode range is exceeded
- Applications: Audio, Communications & Networking, Signal Processing
| Amplifier Type |
General Purpose Amplifier |
|---|---|
| Number of Channel |
1 |
| Output Current Per Channel |
25 mA |
| Input Bias Current (Ib) |
0.5 uA |
| Gain Bandwidth Product (GBP) |
1 MHz |
| Input Offset Voltage (Vos) |
6 mV |
| Slew Rate (SR) |
0.5 V/us |
| CMRR (dB) |
70 |
| Voltage Gain (dB) |
106.02 |
| Technology |
Bipolar |
| Max Dual Supply Voltage |
±18 V |
| Min Dual Supply Voltage (V) |
± 5 |
| Max. Operating Current (mA) |
2.8 |
| Operating Temperature (°C): |
0 to 70 |
| Dimensions (mm) LxWxH |
9.27 x 6.35 x 3.3 |
