Description
This is a Lithium battery protection board, often known as a battery management system, for LiFePO4 batteries. The board is square in design and lightweight, making it simple to store and move. Overcharging and over-discharging protection, as well as short circuit and overcurrent protection, are all included on the board. This board may also be used to charge lithium batteries, as long as they are rechargeable. We can construct a battery pack with a voltage rating of up to 15V DC by combining 4 LiFePO4 electric cells with this BMS system.
Specifications
| Single overcharge detection voltage | 3.07V±0.025V DC |
| Overcharge detection delay time | 1.5 Second |
| Single overcharge release voltage | 3.60V±0.04V |
| Cell balance detection voltage | 3.5V±0.025V |
| Cell balance release voltage | 3.50V±0.025V |
| Balance Current | 70mA±10mA |
| Single over-discharge detection voltage | 2.10V±0.08V |
| Over-discharge detection delay time | 1.5s |
| Single over-discharge release voltage | 2.40V±0.1V |
| Quiescent Current | ≤40µA |
| Sustainable Discharge Current | 6A |
| Sustainable Charging Current | 6A |
| Stop Charging at Temp. | >50°C |
| Stop Discharging at Temp. | >70°C |
| Size | 71x16x2.4mm |
| Country of Origin | China |
