Description
- Floating channel designed for bootstrap operation
- Fully operational to +600 V
- Tolerant to negative transient voltage, dV/dt immune
- Gate drive supply range from 10 V to 20 V
- Undervoltage lockout
- 3.3 V, 5 V, and 15 V input logic compatible
| Package/Case |
PDIP-8 |
|---|---|
| Mounting Type |
Through Hole |
| No. of Drivers |
2 |
| No. of Output |
2 |
| Maximum Supply Voltage (V) |
20 |
| Minimum Supply Voltage (V) |
10 |
| Max. Output Current (A) |
130 mA |
| Rise Time |
170 ns |
| Fall Time |
90 ns |
| Propogation Delay-Max (ns) |
820 |
| Logic Type |
CMOS, TTL |
| Operating Temperature (°C): |
-40 to 125 |
| Maximum Turn-Off Delay-Time (nS) |
150 |
| Maximum Turn-On Delay-Time (nS) |
650 |
| Dimensions in mm (LxWxH) |
10.92 x 7.11 x 5.33 |
| Shipping Weight | 0.005 kg |
| Shipping Dimensions | 8 × 6 × 3 cm |
