Description
- Single chip USB to asynchronous serial data transfer interface
- Entire USB protocol handled on the chip – No USB-specific firmware programming required
- UART interface support for 7 or 8 data bits, 1 or 2 stop bits & odd/even/mark/space/no parity
- Fully assisted hardware or X-On / X-Off software handshaking
- In-built support for event characters and line break condition
- New USB FTDIChip-ID feature
- New configurable CBUS I/O pins
- Auto transmit buffer control for RS485 applications
- Transmit and receive LED drive signals
| Package/Case |
SSOP-28 |
|---|---|
| Minimum Supply Voltage (V) |
1.8 |
| Maximum Supply Voltage (V) |
5.25 |
| Max. Operating Current (mA) |
25 |
| Product Type |
USB Bridge Controllers |
| Product Series |
FT232 |
| Interface Type |
UART |
| Operating Temperature (°C): |
-40 to 85 |
| Mounting Type |
SMD/SMT |
| Shipping Weight | 0.1 kg |
| Shipping Dimensions | 8 × 6 × 3 cm |
