Description
It's a Coaxial Pure Copper 3+1 CCTV White Cable 90 Meter. The Coaxial Pure Copper 3+1 CCTV Cable in White, spanning a length of 90 meters, is an exceptional choice for ensuring top-notch video surveillance in both residential and commercial settings. Crafted from high-quality pure copper, this cable guarantees optimal signal transmission, reducing signal loss and ensuring that your CCTV system delivers clear and uninterrupted video footage. The 3+1 configuration includes three coaxial cables for video transmission and one additional cable for power, simplifying the installation process. The cable's white color not only complements most environments but also offers a clean and discreet appearance. With durability and reliability at its core, this CCTV cable is an indispensable component for maintaining security and peace of mind.
Features
- Core Outer Diameter - 1.35±0.10mm
- Conductor Type - Solid Annealed Bare Copper Conductor
- Colour Code - Red, Yellow & Grey
- No/Size of Wire Video Core- 01/0.60± 0.015mm
- Video Core Insulation- HDPE
- No of Video Core- One
- Colour Video Code- Natural
- Shielded- Al-Mylar
- Braiding- CCA braiding (48 wire/0.12 ± 0.01mm)
- Video Core Jacketng- HDPE
- Colour of Jacket- Black
- Video Core OD- 2.50 ±0.20mm
- Material PVC- PVC
- Colour of Jacketng- White
- Thickness of Outer Jacket- 0.65 mm (Nom.)
- Outer Dia.- 5.70 ± 0.30mm
- Sequental Marking-Every Meter
- Standard Length- 90 Meter
| Specifications | |
|---|---|
| Compatability | CCTV |
| Dimensions | 257mmx90mmx260mm |
| Model | SP2-CCTV-3+1-90M |
| Type | CCTV Coaxial Cable |
| Material | Copper |
| Cable Length | 90 Meter |
| Colour | White |
| Brand | Shivpriya Plus2 |
