Description
The CD40175BE comprises four identical D-type flip-flops, each featuring an independent DATA D input and complementary Q and Q\ outputs. The CLOCK and CLEAR inputs are shared across all flip-flops. Data is transferred to the Q outputs upon the positive transition of the clock pulse. A low level on the CLEAR input simultaneously resets all four flip-flops. This device can be utilized as shift register elements or as T-type flip-flops for toggle and counter applications.
Features:
- Output is compatible with either two HTL loads, two low-power TTL loads, or one low-power Schottky TTL load.
- It is functionally equivalent to TTL74175.
- Exhibits standardized and symmetrical output characteristics.
