Description
It's a CAT6 Ethernet Cable Gray SP2CAT6-UTP 305 Meter. The CAT6 Ethernet Cable in gray, specifically the SP2CAT6-UTP model, offers outstanding networking capabilities over an impressive length of 305 meters. This cable is designed to meet the demanding requirements of modern data transmission, providing reliable and high-speed connectivity for a variety of applications. With its Category 6 classification, it supports data transfer rates of up to 10 gigabits per second, making it ideal for both residential and commercial networking needs. The gray color adds a professional touch to any installation, ensuring it blends seamlessly into various environments while delivering exceptional performance and data integrity. Whether you're setting up a home network or wiring an entire office, the SP2CAT6-UTP cable is a dependable choice for efficient data transmission.
Features
- Conduct Type- Solid Bare Electrolytic Grade Copper
- Nominal Conductor Diameter- 24 AWG (.50 ± 0.015 mm)
- Insulation - Polyethylene (HDPE)
- No. of Pair- 4, Each pair Twisted
- Pairing- Twisted into Two core
- No of Video Core- One
- Outer Sheath Material- PVC
- Colour of Sheath- Grey
- Approximate OD- 5.7 ± 0.30 mm
- Rip Cord- Yes
- Cross Filler- HDPE
- Sequential Marking- Every Meter
- Resistance Unbalance- 5% Max
- Conductor Resistance- 93.8Ω/1000 mtr @20°c Max
- Mutual Capacitance- 5.6nf/100Mtr. Max
- Packing- 100 Mtrs
- Temperature Rating- -20 to +60°C
- Installation Temperature- 0 to 50°C
- Standard Length - 305 meter
Specifications | |
---|---|
Wire Gauge | 24 |
Color | Gray |
Model | SP2CAT6-UTP-305M |
Type | Ethernet Cable |
Cable Length | 305 Meter |
Brand | Shivpriya Plus2 |
