Description
The BTA20 Triacs use high-performance glass passivated chip technology. The Snubberless concept offers suppression of the RC network and is suitable for applications such as phase control and static switching on inductive or resistive load. Thanks to their clip assembly technique, the BTA20 Triacs provide superior performance in surge current handling capabilities.
Specifications
| Brand | STMicroelectronics |
| Series | BTA20-700 |
| Non Repetitive On-State Current | 210A |
| Rated Repetitive OFF-State Voltage (VDRM) | 700V |
| Off-State Leakage Current @ VDRM IDRM | 10uA |
| On-State Voltage | 1.7V |
| Max. Holding Current | 50mA |
| Gate Trigger Voltage (Vgt) | 1.5V |
| Gate Trigger Current (Igt) | 35mA |
| Operating Temperature | -40°C to 125°C |
| Mounting Style | Through Hole |
| Package | TO-220-3 |
| Product Type | Triac |
| Subcategory | Thyristors |
| Country of Origin | China |
