Arduino UNO Curve Tracer Shield

Save 21%
Sold By: HatchnHackSKU: G14-61

Price:
Sale price₹ 146.00 Regular price₹ 184.00

Tax included Shipping calculated at checkout

Min Qty: 1

Description

The Semiconductor Curve Tracer Shield for Arduino can be used to plot I-V characteristics curves of resistors, diodes, LEDs, NPN and N-MOS transistors on an oscilloscope, a PC, or a smartphone over Bluetooth.

The relationship between the voltage applied across an electrical device and the current flowing through it is represented graphically by an I-V curve (short for 'current-voltage characteristic curve'). It's one of the most common ways to figure out how an electrical component in a circuit works. The shape and features of the curve can also be used to extract key properties of electronic devices, giving you a better understanding of how they work.



Specification
Operating Voltage 5V-12V DC
PCB Size 62x53.2mm
Application Plotting I-V Characteristics Curve
Country of Origin China
