Description
- Contact type: NC / COM / NO
- Input current: ≥300mA
- Input voltage: DC 5V
- Support in all Windows OS.
- Onboard square USB interface, stable connection.
- Use imported high-performance USB control chip.
- Application code: Green indicates that the relay is closed, the red disconnect
- Military grade PCB board production.
| Operating Voltage (VDC) |
5 |
|---|---|
| Trigger Voltage (VDC) |
5 |
| Trigger Current (mA) |
20 |
| Switching Voltage (VAC) |
250@10A |
| Switching Voltage (VDC) |
30@10A |
| Opt. Relative Humidity(RH) |
20% ～ 85% |
| Storage condition (℃) |
-40 to 80 |
| Operating Temperature (°C): |
-40 to 85 |
| Length (mm): |
63 |
| Width (mm): |
41 |
| Height (mm): |
17 |
| Weight (g): |
30 |
| Shipping Weight | 0.033 kg |
| Shipping Dimensions | 8 × 6 × 3 cm |
