Description
This 4S 100A BMS was created with 3.2V LiFePO4 cells in mind. It features excellent and consistent charging and discharging protection. The battery core is balanced, the balance current is appropriate, and the balanced heat is reasonable, all of which have no effect on the battery pack's performance.
- Four series of inverter with high current 100A, four series of 3.2V lithium iron phosphate battery protection plate, four series of 3.7V lithium battery protection plate with balanced charge
- Note: 3A discharge above the current point, the battery discharge rate of 3C or more
- Short circuit protection: protection, delay self-recovery
Specification
| Model | HX-4S-F100A |
| Max. working Current | 100A |
| Max. Instantaneous Current | 120A |
| Overshoot Voltage Range | 4.2V ±0.05V |
| Over Voltage Range | 2.5V ±0.08V |
| Static Current | <30µA |
| Charge Voltage | 16V |
