Description
PTFE is a higher grade insulating polymer compared to other fluorocarbons that are used in the extrusion process. PTFE-insulated equipment/hookup wires are commonly used for internal wiring of various electronic and electrical equipment, as well as for other electrical uses. They are most suited for usage in high-frequency signal-processing equipment. Because of the uniformity of the insulation layer surrounding the conductor and the very low dielectric constant of PTFE, it is possible to transmit high-frequency signals with little signal losses as compared to other wires, resulting in high-quality signal transmission.
Specifications
| Material | PTFE (Teflon) |
| Gauge | 24 AWG |
| Number of Strands | 7 |
| Single Strand Gauge | 32 AWG |
| Current Rating | 6~15 Amp |
| Length | 1 Meter |
| Colour | Black/Red/Yellow/White/Blue/Cyan |
| Country of Origin | China |
