Description
This product is a new energy-saving device that uses a microwave sensor mould and an integrated circuit with a high-frequency electromagnetic wave (5.8GHz). It combines functions such as automation, convenience, safety, energy conservation, and practicality. Detectors are responsible for the wide detecting field. It functions by detecting human movement. When one reaches the detection field, the load can begin immediately and automatically recognize day and night. Its setup is simple, and it has a wide range of applications. Doors, panes of glass, and thin walls can all be penetrated for detection. Microwave Sensor detects human movements over a large field of view. This microwave Sensor, with 360-degree motion detection capabilities, keeps your home and office secure by generating an alarm as soon as it detects any human motion.
Function
- Can identify day and night: It can work in the daytime and at night when it is adjusted on the "sun" position (max). It can work in the ambient light of less than 3 LUX when it is adjusted to the "3" position (min). As for the adjustment pattern, please refer to the testing pattern.
- Sensitivity Adjustable: It can be adjusted according to using location. The detection distance of low sensitivity could be only 1 meter and high sensitivity could be 8m.
- Time Delay Retrigger: When it receives the second induction signal within the first induction, it will restart to time from the moment.
- Time-Delay Adjustable: Minimum time is 10sec±3sec, Maximum time is 12min±1min.
Features
- Microwave Base
- LUX, Sensitivity adjustable
- Highly Sensitive
- Time-Delay is adjustable
Specifications
Voltage | 220-240V AC |
Detection Range | 360° |
Detection Distance | 1-8m |
Power frequency | 50/60Hz |
Ambient Light | 3~2000 LUX |
Time Delay | Min. 10sec±3sec, Max. 12min± |
Rated Load | 800W |
HF System | 5.8GHz CW radar, ISM band |
Transmission Power | <0.2mW |
Installing Height | 2-6 Meter |
Power Consumption | 0.9W |
Detection Motion Speed | 0.6-1.5m/s |
Country of Origin | China |
