Description
- Installation surface must be smooth, clean and dry
- The part of LED components cannot be fixed on the surface of the sharp edges
- The strip should not be collided or crushed
- The strip can be cut following the cutting lines
- 24-bit color control (8-bit PWM per channel); 16.8 million colors per pixel
- The one-wire digital control interface
- Each RGB LED draws approximately 50 mA at 5 V with red, green, and blue at full brightness
| Model |
BTF-5V-60L-W |
|---|---|
| Strip Length (Meter) |
1 |
| Strip Color |
White |
| Width (mm): |
12 |
| Thickness (mm): |
2.36 |
| Input Supply Voltage (VDC) |
5 |
| Maximum Power (W) |
90 |
| Wtareproof |
NO |
| Storage Temperature(°C) |
-40 to 80 |
| Operating Temperature (°C): |
-25 to +60 |
| Weight (g): |
20 |
| Shipping Weight | 0.022 kg |
| Shipping Dimensions | 6 × 6 × 2 cm |
