12x12x12mm Tactile Push Button Switch
Review: 5 - "A masterpiece of literature" by , written on May 4, 20020
Great

12x12x12mm Tactile Push Button Switch

In Stock - SKU: 6EE17

5.00
[ ₹ 4.24 + ₹ 0.76 (18% GST) ]
  • Switching Type: Momentary
  • Mounting Type: Through hole
  • Contact Resistance: 50m ohm
  • Operation Force: 3-5 N
  • Protection Grade: IP65
  • Order within

Tactile push button switch is Normally Open switch. The tactile button connects the circuit for the time it is kept pressed and as soon as it is released the circuit is disconnected. The Tactile Push-button has 4 pins. Two pins are connected internally. These Tactile push-buttons features a through-hole design. Its high precision mechanism offers acute operation and long life. It is majorly used as standard input buttons in electronics circuits. Tactile push buttons have a long life, it works fine for more than 300000 cycles. Tactile buttons are waterproof.

Tactile push button switch is Normally Open switch. The tactile button connects the circuit for the time it is kept pressed and as soon as it is released the circuit is disconnected. The Tactile Push-button has 4 pins. Two pins are connected internally. These Tactile push-buttons features a through-hole design. Its high precision mechanism offers acute operation and long life. It is majorly used as standard input buttons in electronics circuits. Tactile push buttons have a long life, it works fine for more than 300000 cycles. Tactile buttons are waterproof.

On/Off Function Push to ON
Switching Type Momentary
Mounting Type Through Hole
Contact Material Aluminium Alloy
Contact Resistance 50mΩ
Insulation Resistance 100MΩ
Operation Force About 3-5N
Operation Stroke 1.05mm
Body Material Plastic
Mechanical and Electrical Life 300,000 Cycles
Protection Grade IP65
Dimension (LxWxH) 12x12x12 mm
