Description
These are Carbon Film resistors with a value of 1.5k ohm 1/8W and a tolerance of ±5%. These Axial resistors are cylindrical in shape with copper-plated steel leads extending from each end. Carbon Film Resistors limit the flow of electric current using Carbon Film. The printed colour code rings, which are Brown, Green, Red, and Gold for these 1K5 resistors, make it easy to identify the value of these resistors.
Applications
- It's used in the Current limiting circuit
- It's used in voltage divider applications
- It's used for the biasing circuit
- Resistors are used in sensor circuits and measurement systems to convert physical quantities such as temperature, light, or strain into electrical signals
- It can be employed to drop voltage across a circuit, acting as a voltage divider or voltage-dropping element.
Features:
- Its mounting style is Through hole
- It has two pins
| Specifications | |
|---|---|
| Resistance | 1.5K Ohm |
| Lead Thickness | 0.38 |
| Tolerance | 5% |
| Mounting Type | Through Hole |
| Type | Resistor |
| Power | 1/8W |
